Technical Details
- Category 6A 500 MHz, 10GBase-T
- Category 6 250 MHz
- Category 5E 1000 MHz
- ISO/IEC 11801 3rd edition, EN 50173-1, PoE/PoE+ (IEEE 802.3af, 3at)
- Metal Lock Buckle Design for premium project
- RJ45 jack, 8P8C
- Tool-free
- Unshielded
- Intelligent cable bundle for option
- AWG-range: 26 … 22
- Material: Zinc die-casting
- Contact material: Phosphor bronze
- Contact coating: Nickel, gold-plated 0.5 µ
- Insertion force: Max. 30N
- Operating temperature range: -20 °C to +70 °C
- Mating cycles: ≥ 750
