Technical Details
- Protection Grade: IP68
- Capacity: 24 -48F. Could be installed with 4 trays. 12F/per tray in max.
- Ports: 4 port
- Sealing of housing : mechanical seal for housing,
- Sealing of port: heat-shrink seal or mechanical seal for ports
- Installation: wall mounting, aerial, direct burial. etc.
- Performance: meet all the industry standard performance tests from YD/T 814.1-2013 Closure for Optical Fiber Cables (ICS 33.180.99)
- Satisfactory space for the placement of fiber joints and fiber storage, preventing the joints from being influenced by the external environment
- Dimension: 288×ф178 MM
