Technical Details
- Protection Grade: IP68
- Capacity: 192F, 4*48core
- Ports: 6 ports joint box, 3 in 3 out,available specification is the cable Φ 10 to 18.
- Sealing: screw structure, silica gel for squeezing seal
- Installation: wall mounting, aerial, duct mounting, underground
- Performance: meet all the industry standard performance tests from YD/T 814.1-2013 Closure for Optical Fiber Cables (ICS 33.180.99) and strict tests like IK10 and TCT (*10)
- Dimension: 555×217×120 MM
- Inner box : 570×235×160 MM
- Outer Carton: 590×490×450 MM, 6pcs per outer carton
