Power Distribution Unit

Safe and professional power in 19 inch range.

Technical Details

  • Optimized for rack installation with 220-240V 50-60 Hz
  • Aluminium / ABS profile
  • 2pcs angle profiles for cabinet mounting
  • Plastic components made by ABS UL-94V-0
  • Grounding on aluminium profile
  • Control Modular: On/Off switch, Surface protection, Overload protection,Residual current circuit breaker, power meter, etc.
  • Colour: Black

Order Information

Part Number Breakdown

RPU
H
T
M
NN
S
CC
P
LL
Height
Type
Material
Way Number
Type
Control System
Plug
Power Cable
1=1U H=horizontal A=aluminum 06=6 ways D=Schuko 0S=no switch D=Schuko 2M=2 meters
1.5=1.5U V=Veritical B=ABS 08=8 ways F=France 1S=switch F=France 5M=5 meters
12=12 ways B=UK AS=single air switch B=UK
16=16 ways I=Italy AD=double air switch I=Italy
C13=IEC13 SP=surger protector C14=IEC14
PM=power meter

Logistics

Not available now.

Download

Not available now.

Accessories List

Not available now.
